Series 30i-MODEL A, Real time custom macro Additional Manual Page 22

Additional Manual
Ed. Date Design Description
Date Jan.07.’04 Design. Apprv.
page
ＤＳ０１００
－
０４
３版
20/64
FANUC Series 30i-MODEL A
Real time custom macro
A-79350EN
Title
Draw
No.
Custom macro variables
With real time custom macros, a part of the custom macro variables (part of the
system variables) can be handled.
System variables
With real time custom macros, position-related information among the system
variables of the custom macros can be handled.
・ Position information #100001 to #100182 (Attribute: Read only)
Block end position #100001 to #100032
Current position (machine coordinate system) #100051 to #100082
Current position (workpiece coordinate system) #100101 to #100132
Skip position #100151 to #100182
By readying the values of system variables #100001 to #100182, the end position of
the previous block, the current positions (machine coordinate system and workpiece
coordinate system), and skip signal position can be found.
Variable
No.
Position information Coordinate system
#100001
#100002
：
#100032
Block end position on 1st axis
Block end position on 2nd axis
：
Block end position on 32nd
axis
Workpiece
coordinate system
#100051
#100052
：
#100082
Current position on 1st axis
Current position on 2nd axis
：
Current position on 32nd
axis
Machine coordinate
system
#100101
#100102
：
#100132
Current position on 1st axis
Current position on 2nd axis
：
Current position on 32nd
axis
Workpiece
coordinate system
#100151
#100152
：
#100182
Skip position on 1st axis
Skip position on 2nd axis
：
Skip position on 32nd axis
Workpiece
coordinate system
