Feedrate specification range
The table below indicates the feedrate specification range.
Linear axis Rotation axis
Metric input
(mm/min)
Inch input
(inch/min)
(deg/min)
IS-A 10. to 240000. 0.1 to 6553.5 10. to 240000.
IS-B 1. to 65535. 0.01 to 655.35 1. to 65535.
IS-C 0.1 to 6553.5 0.001 to 65.535 0.1 to 6553.5
IS-D 0.01 to 655.35 0.0001 to 6.5535 0.01 to 655.35
IS-E 0.001 to 65.535 0.00001 to
0.65535
0.001 to 65.535
NOTE
1. Be sure to set the following parameters to 0:
F10 (bit 3 of parameter No. 8002)
EFD (bit 4 of parameter No. 8006)
PF1 (bit 4 of parameter No. 8002)
PF2 (bit 5 of parameter No. 8002)
When a value other than 0 is set, the feedrate specification range
changes, depending on the set parameter.
2. A value less than the lowest feedrates indicated above is discarded.
・Feedrate override
With bit 2 (OVE) of parameter No. 8001, whether to use the feedrate override signal
(*FV) for an NC statement or the feedrate override signal (*EFV) dedicated to PMC
axis control can be chosen.
NOTE
1. The second feedrate override function cannot be used.
2. The feedrate override function cannot be disabled using #3004.
・Override cancel
With bit 2 (OVE) of parameter No. 8001, whether to use the feedrate override
cancel signal (OVC) for an NC statement or the feedrate override cancel signal
(EOVC) dedicated to PMC axis control can be chosen.
・Operation between blocks
If feed with a specified feedrate is performed in succession in RTM statements,
no stop occurs between blocks, but the next block is executed. With the
accumulated pulse zero check signal (ELCKZg) for PMC axis control, an
accumulated pulse zero check can be made between blocks specifying feed with
a specified feedrate.
