Command details
Rapid traverse
A movement is made at a rapid traverse rate on an axis from the current position to
the point separated by a specified value.
Format
// ZDO ;
G91 G00 IP ___ ;
ZEND ;
G91 ：G code for incremental command
IP __：Travel distance
NOTE
1. Only one axis can be specified in one block.
2. The absolute command (G90) cannot be specified.
3. The rapid traverse overlap function cannot be used.
4. When using this function, be sure to set bit 0 (RPD) of parameter No.
8002 to 0.
・Rapid traverse override
With bit 2 (OVE) of parameter No. 8001, whether to use the rapid traverse
override signal (ROV) for an NC statement or the rapid traverse override signal
(EROV) dedicated to PMC axis control can be chosen.
NOTE
1. Even if bit 4 (RF0) of parameter No. 1401 is set to 1, rapid traverse
does not stop with a cutting feed override of 0%.
