FANUC Series 30i-MODEL A
Real time custom macro
A-79350EN
Title
Draw
No.
Linear axis Rotation axis
Metric input
(mm/rev)
Inch input
(inch/rev)
(deg/rev)
T
series
0.001 to 65.535 0.000001 to
0.65535
0.001 to 65.535
M
series
0.01 to 500.00 0.0001 to 6.5535 0.01 to 500.00
・Feedrate override
With bit 2 (OVE) of parameter No. 8001, whether to use the feedrate override signal
(*FV) for an NC statement or the feedrate override signal (*EFV) dedicated to PMC
axis control can be chosen.
NOTE
3. The second feedrate override function cannot be used.
4. The feedrate override function cannot be disabled using #3004.
・Override cancel
With bit 2 (OVE) of parameter No. 8001, whether to use the feedrate override
cancel signal (OVC) for an NC statement or the feedrate override cancel signal
(EOVC) dedicated to PMC axis control can be chosen.
・Operation between blocks
If feed with a specified feedrate is performed in succession in RTM statements,
no stop occurs between blocks, but the next block is executed. With the
accumulated pulse zero check signal (ELCKZg) for PMC axis control, an
accumulated pulse zero check can be made between blocks specifying feed with
a specified feedrate.
NOTE
1. The error detect signal (SMZ) cannot be used.
2. With the accumulated pulse zero check signal (ELCKZg) for PMC axis
control, an accumulated pulse zero check can be made between
blocks specifying feed with a specified feedrate for feed on the same
axis only.
・Acceleration/deceleration time constant
For an acceleration/deceleration time constant to be used for feed with a
specified feedrate in an RTM statement when exponential
acceleration/deceleration is used, whether to use the time constant for an NC
statement or the time constant dedicated to PMC axis control can be chosen
using parameter No. 8030.
NOTE
1. Look-ahead acceleration/deceleration before interpolation cannot be
used.
