Series 30i-MODEL A, Real time custom macro Additional Manual Page 60

Additional Manual
Ed. Date Design Description
Date Jan.07.’04 Design. Apprv.
page
ＤＳ０１００
－
０４
３版
58/64
FANUC Series 30i-MODEL A
Real time custom macro
A-79350EN
Title
Draw
No.
For the axis being controlled by an RTM statement, the functions disabled for PMC
axis control cannot be used.
Other disabled functions
For the axis being controlled by an RTM statement, the functions listed below as
examples are disabled.
Do not specify these functions for the axis being controlled by an RTM statement.
Feed-forward
Advanced preview feed-forward
Fine acceleration/deceleration
Automatic corner deceleration
Single-digit F feed
Scaling
Coordinate system rotation
Polar coordinate interpolation
Balance cut
Feed stop
Constant surface speed control
Positioning function based on optimal acceleration, etc.
CAUTION
In an RTM statement, do not specify an axis used with any of the
following functions:
1. Feed axis synchronization control
Be sure to set the simple synchronous axis selection signal
(SYNCn) and simple synchronous manual feed axis selection
signal (SYNCJn) of the axis to 0.
2. Axis recomposition
3. Index table indexing
