PS0416 UNABLE TO USE THE AXIS
The specified axis cannot be used.
PS0417 AXIS IS UNABLE TO MOVE
The specified axis is placed in the inoperative state.
PS0418 ILLEGAL FEED SETTING
An incorrect feedrate is set.
PS0419 ILLEGAL DISTANCE SETTING
A travel distance beyond the specifiable range is specified.
PS0420 CONSTANT NUMBER P
A subprogram is specified not by using a constant.
PS0421 ILLEGAL ARGUMENT G54
With G65, an invalid argument, L, is used.
PS0422 ILLEGAL ARGUMENT G54
With G65, an invalid argument is used.
PS0423 NO PMC AXIS CONTROL OPTION
The option for PMC axis control is missing.
PS0424 MULTIPLE AXES IN ONE GROUP
Multiple axes are using one group.
PS0425 ONE AXIS USE MULTIPLE GROUPS
One axis is using multiple groups.
Supplement
P/S alarm 414 (ILLEGAL PMC AXIS NO.)
First, check the settings of parameter No. 8010 and No. 8011. If this alarm is
issued when both parameters are set correctly, enter the reset signal (ECLRg) for
PMC axis control of the related group then reexecute.
