FANUC Series 30i-MODEL A
Real time custom macro
A-79350EN
Title
Draw
No.
Parameter
#7 #6 #5 #4 #3 #2 #1 #0
8011 XRT
[Input type] Parameter input
[Data type] Bit axis
# 0 XRT With a real time custom macro , an axis for which the group specified
by parameter No.8010 is used is:
0: Not controlled.
1: Controlled.
NOTE
1. This parameter is invalid for an axis for which parameter No.
8010 is set to 0 or a value beyond the specifiable range.
2. If multiple axes are assigned to the same group with
parameter No. 8010, these axes cannot be controlled by a real
time custom macro. If multiple axes are assigned to the same
group, be sure to set this bit to 0.
3. When this parameter (No. 8011) is set to 0, the axis is
placed under PMC axis control.
Previous page
Next page
