FANUC Series 30i-MODEL A
Real time custom macro
A-79350EN
Title
Draw
No.
Operation in each event
If an event such as an emergency stop or alarm occurs during execution of an RTM
command, the NC command and RTM command generally operate as indicated
below.
Event NC command RTM command consisting of a
macro command
RTM command including an axis control
command
P/S alarm issued
in NC command
execution
Operation stops when
the block involving the
P/S alarm cause starts.
The RTM command stops when
the NC command stops.
If the RTM statement being executed
when the NC command stops is an axis
control command, operation on the axis
stops when the block stops.
Alarm issued in
RTM command
execution
Operation stops with the
alarm.
The RTM statement stops at
that point. Other RTM
commands stop when the NC
command stops.
The RTM statement stops at that point.
Other RTM commands stop operation on
the axis when axis control by the RTM
statement being executed when the NC
statement stops ends.
Single block (SBK
signal)
Operation stops when
the command being
executed ends.
The RTM command is
suspended when the NC
command stops.
When the NC command restarts,
the RTM command restarts.
If the RTM statement being executed
when the NC command stops is an axis
control statement, operation on the axis
stops when the block ends.
Feed hold (*SP
signal)
A gradual stop occurs. The RTM command stops when
the NC command stops.
When the NC command restarts,
the RTM command restarts.
If the RTM statement being executed
when the NC command stops is an axis
control statement, operation on the axis
stops when the block ends.
NC command
stopped by a reset
(ERS signal)
A gradual stop occurs,
and the command also
ends.
The RTM command stops when
the NC command stops.
If the RTM statement being executed
when the NC command stops is an axis
control command, operation on the axis
stops when the block ends.
Emergency stop An immediate stop
occurs, and the
command also ends.
The command immediately
ends.
Operation on the axis immediately stops,
and the command also immediately
ends.
End of the NC
command
- If the RTM command being
executed is a one-shot RTM
command, the command ends.
If the RTM command being
executed is a modal RTM
command, the command
continues execution.
If the one-shot RTM command being
executed when the NC command ends is
an axis control command, operation on
the axis stops when the block ends.
Machine lock
(MLK signal)
The NC command is
valid.
The RTM command operates. The RTM command can be enabled.
For details, see the description of the
axis control command.
Dr
y
run
(
DRN The NC command is The RTM command operates. The RTM command can be enabled.
