Series 30i-MODEL A, Real time custom macro Additional Manual Page 54

Additional Manual
Ed. Date Design Description
Date Jan.07.’04 Design. Apprv.
page
ＤＳ０１００
－
０４
３版
52/64
FANUC Series 30i-MODEL A
Real time custom macro
A-79350EN
Title
Draw
No.
NOTE
1. The error detect signal (SMZ) cannot be used.
2. With the accumulated pulse zero check signal (ELCKZg) for PMC axis
control, an accumulated pulse zero check can be made between
blocks specifying feed with a specified feedrate for feed on the same
axis only.
・Acceleration/deceleration time constant
For an acceleration/deceleration time constant to be used for feed with a
specified feedrate in an RTM statement when exponential
acceleration/deceleration is used, whether to use the time constant for an NC
statement or the time constant dedicated to PMC axis control can be chosen
using parameter No. 8030.
NOTE
1. Look-ahead acceleration/deceleration before interpolation cannot be
used.
