・ Servo positional deviation #100251 to #100282 (Attribute: Read only)
By reading the values of system variables #100251 to #100282, the servo positional
deviation on each axis can be found.
Variable
No.
Position information
#100251
#100252
：
#100282
Servo positional deviation
on 1st axis
Servo positional deviation
on 2nd axis
：
Servo positional deviation
on 32nd axis
NOTE
1 The value of a variable with a number greater than the number of
controlled axes is undefined.
・ Remaining travel distance #100801 to #100832 (Attribute: Read only)
By reading the values of system variables #100801 to #100832, the remaining travel
distance on each axis can be read.
Variable
No.
Position information
#100801
#100802
：
#100832
Travel distance on 1st axis
Travel distance on 2nd axis
：
Travel distance on 32nd axis
NOTE
1 The value of a variable with a number greater than the number of
controlled axes is undefined.
NOTE
1. System variables not described here are unusable.
2. The name of a system variable cannot be specified.
Do not specify a command as indicated below.
//1 #RV[0]=[#_ABSOT[1]] ;
Local variables
The local variables(#1 to #33) cannot be used.
