Feed with a specified feedrate (feed per minute)
A movement is made at a feedrate specified in F on an axis from the current position
to the point separated by a specified value.
Format
// ZDO ;
G94 G91 G01 IP ___ F___ ;
ZEND ;
G94 ：G code for feed per minute
G91 ：G code for incremental command
IP __：Travel distance
F__ ：Feedrate command (mm/min or inch/min)
NOTE
1. Only one axis can be specified in one block.
2. The absolute command (G90) cannot be specified.
3. The block overlap function cannot be used.
4. When IS-A is used, a feedrate below 10 mm/min is discarded.
5. The feedrate cannot be clamped to a parameter-set maximum
cutting feedrate.
6. No time is added to the cumulative cutting time.
7. Even if this command is executed, the cutting in-progress signal
is not output.
8. The operation between blocks for feed with a specified feedrate is
performed in the cutting mode.
9. For this command, the feedrate arrival signal SAR (G029.4) cannot
be used.
