  2. Series 30i-MODEL A, Real time custom macro

Series 30i-MODEL A, Real time custom macro Additional Manual Page 49

Additional Manual
Ed. Date Design Description
Date Jan.07.’04 Design. Apprv.
page
ＤＳ０１００
－
０４
３版
47/64
FANUC Series 30i-MODEL A
Real time custom macro
A-79350EN
Title
Draw
No.
CNC→PMC
Overtravel negative direction signal EOTNg
Overtravel positive direction signal EOTPg
Axis movement in-progress signal EGENg
Alarm signal EIALg
Accumulated pulse zero check in-progress signal ECKZg
In-position signal EINPg
(The signals above are group-by-group signals: the
addresses of group 1 are indicated.)
#7 #6 #5 #4 #3 #2 #1 #0
F130 EOTNA#1 EOTPA#1 EGENA#1 EIALA#1 ECKZA#1 EINPA#1
Control axis selection state signal *EAXSL
Override 0% signal EOV0
(The signals above are path-by-path signals: the
addresses of path 1 are indicated.)
#7 #6 #5 #4 #3 #2 #1 #0
F129 *EAXSL EOV0
Distribution completion signal EADENn
Control in-progress signal EACNTn
(The signals above are axis-by-axis signals: the
addresses of axes 1 to 8 are indicated.)
#7 #6 #5 #4 #3 #2 #1 #0
F112 EADEN8 EADEN7 EADEN6 EADEN5 EADEN4 EADEN3 EADEN2 EADEN1
#7 #6 #5 #4 #3 #2 #1 #0
F182 EACNT8 EACNT7 EACNT6 EACNT5 EACNT4 EACNT3 EACNT2 EACNT1
