FANUC Series 30i-MODEL A
Real time custom macro
A-79350EN
Title
Draw
No.
PMC interface signals used with an RTM statement
The PMC interface signals used or referenced for axis control using an RTM
statement are indicated below.
For details of each signal, refer to the specifications for PMC axis control.
PMC→CNC
Reset signal ECLRg
Axis control temporary stop signal ESTPg
Block stop signal ESBKg
Accumulated pulse zero check signal ELCKZg
Override cancel signal EOVCg
Feedrate override signals EFOV1 to 7g
(The signals above are group-by-group signals: the
addresses of group 1 are indicated.)
#7 #6 #5 #4 #3 #2 #1 #0
G142 ECLRA#1 ESTPA#1 ESBKA#1 ELCKZA#1
#7 #6 #5 #4 #3 #2 #1 #0
G150 EOVCA#1
#7 #6 #5 #4 #3 #2 #1 #0
G151 *EFOV7A#1 *EFOV6A#1 *EFOV5A#1 *EFOV4A#1 *EFOV3A#1 *EFOV2A#1 *EFOV1A#1 *EFOV0A#1
Dry run signal EDRNp
Manual rapid traverse selection signal ERTp
Overall cancel signal EOVCp
Rapid traverse override signal EROV1, 2p
Feedrate override signal EFOV1 to 7p
(The signals above are path-by-path signals: the
addresses of path 1 are indicated.)
#7 #6 #5 #4 #3 #2 #1 #0
G150 EDRN#1 ERT#1 EOVC#1 EROV2#1 EROV1#1
#7 #6 #5 #4 #3 #2 #1 #0
G151 *EFOV7#1 *EFOV6#1 *EFOV5#1 *EFOV4#1 *EFOV3#1 *EFOV2#1 *EFOV1#1 *EFOV0#1
Control axis selection signal EAXn (Axis-by-axis signal: the addresses of axes 1 to
8 are indicated.)
#7 #6 #5 #4 #3 #2 #1 #0
G136 EAX8 EAX7 EAX6 EAX5 EAX4 EAX3 EAX2 EAX1
For the axis used with an RTM statement, this signal (EAXn) need not be controlled.
Axis control superposition command signal EASIPn (Axis-by-axis signal: the
addresses of axes 1 to 8 are indicated.)
