2 CPU 3-path control function Additional Manual Page 61

Additional Manual
60
/
60
FANUC Series 16i-TB
2 CPU 3-path control function
Specifications
A
-78884E
ED. DATE DESIG. DESCRIPTION
TITLE
DRAW.NO.
01 Aug.01.’02 Newly registered
SHEET
Spindle setting screen
Only for αi / α series
✳
Servo waveform display Graphic display circuit is required.
✳
Display of hardware and software
configuration
O
Servo information screen O
Spindle information screen
Only for αi / α series
✳
Periodic maintenance screen O
Maintenance information screen O
Trouble diagnosis O
Machine alarm diagnosis
✩
Software operator's panel
✩
Software operator's panel general
purpose switch
Software operator's panel is required.
✩
Software operator's panel general
purpose switch expansion
Software operator's panel general
purpose switch is required.
✩
External touch panel interface It is impossible to use with the Touch
panel.
✩
Virtual MDI Key for display link Touch panel is required.
✩
Virtual MDI Key for HSSB Touch panel is required.
✩
English O
Japanese (Chinese character)
✩
German/French
✩
Italian
✩
Chinese
✩
Spanish
✩
Korean
✩
Portuguese
✩
Polish
✩
Hungarian
✩
Swedish
✩
Czech
✩
Multi-language display
Dutch -
Data protection key 4 types O
Erase CRT screen display O
Parameter set supporting screen O
Machining condition selecting screen
✩
Data input/output
Reader/puncher (Ch.1) interface
✩
Reader/puncher interface
Reader/puncher (Ch.2) interface
✩
Input/output simultaneous operation Only for 1 path -
Remote buffer Only for 1 path -
High-speed remote buffer A Only for 1 path -
High-speed remote buffer B Only for 1 path -
Data server Only for 1 path -
External I/O device control
✩
DNC1 control Uploading/downloading a part program,
Reading/writing CNC data, Transfer of
PMC data, Memory operation control, etc.
-
DNC2 control Only for 1 path
Uploading/downloading a part program,
Reading/writing CNC data, Transfer of
PMC data, Memory operation control, etc.
-
Modem card control There are some limitations in case of 160i
/180i /210i /160is/180is/210is.
O
External tool offset
✩
External message
✩
