3.ASSEMBLY HANDLING, DESIGN, AND ASSEMBLY B-65222EN/03
- 128 -
<4> Shift the movable table onto the magnet plate again, then mount
a remaining magnet plate. Note that when the movable table is
shifted, the movable table is pulled toward the magnet plate by
magnetic attraction.
CAUTION
Powerful magnetic attraction is exerted at all times.
When securing magnet plates and a coil slider, be
sure to securely tighten all screws. Do not tighten
the screws temporarily. Until the magnet plates have
been secured, do not remove the tin plate and
corrugated board attached onto the top face of each
magnet plate.
