1. Fanuc
  2. Linear Motor Series

Linear Motor Series Descriptions Page 238

Descriptions
TITLE
DRAW.
No.
2 / 2
Page
FANUC LTD
DESCRIPTIONDESIGNDATE
EDIT
Correction of
“Cables usable for power lines”,
etc.
B-65222EN/03-002
Error correctionT.Tamai
01.10.0501
1. Outline
Errors concerning to applicable lead wire for 9000B and 15000C are corrected.
And other errors are also corrected.
2. Corrections
Ø Page 39, Line 1 (Title) and Page 40, Line 1 (Title)
[Wrong] External thread [Correct] Internal thread
Ø Page 81, Explanation of “- Maximum cutting duty ratio / on time”
[Wrong] Subsection 2.1.4 [Correct] Subsection 2.1.5
Ø Page 96, Positive direction of HEIDENHAIN’s linear encoder
Positive direction of HEIDENHAIN’s linear encoder should not be found by the direction of feedback
cable, but “HEIDENHAIN” label put on the main unit.
£ HEIDENHAIN’s LC191F/LC491F (Head movable)
Positive direction is the opposite side of “HEIDENHAIN” label put on the side of main unit.
£ HEIDENHAIN’s LC191F/LC491F (Main unit movable)
Positive direction is the same side of “HEIDENHAIN” label put on the side of main unit.
NOTE
LC491F has “HEIDENHAIN” label on the top surface of its main unit.
