B-65222EN/03 SPECIFICATIONS 2.SPECIFICATIONS
- 47 -
2.6 APPLICABLE AMPLIFIERS
The FANUC Linear Motor series is driven using the FANUC
servo amplifier α and β series that support the FSSB
interface.
CAUTION
Combining these motors with any amplifier other than
listed below may damage the motor or amplifier.
NOTE
1 For details of amplifiers, refer to the relevant
amplifier descriptions.
2 For selection of a power supply module (PSM), see
Section 2.2, "SPECIFICATION LIST," and Section
2.3, "SELECTING A POWER SUPPLY MODULE
(PSM)," in Part II, "CONFIGURATIONS AND
SELECTION."
3 The applicable amplifiers listed below are
representative examples. You can also use an
amplifier which is not listed when the maximum
current and rated current of the amplifier satisfy the
conditions. In any case, the motor output may be
limited because the used amplifier cannot exceed its
limit, however. Note that when an amplifier which is
not listed below is used, the drive parameters must
also be changed.
For 300D/4
Type of amplifier Name Specification
Connectable
axis
SVM1-20 A06B-6096-H102
SVM2-12/20 A06B-6096-H202 M axis
SVM2-20/20 A06B-6096-H203 L and M axes
SVM2-20/40 A06B-6096-H205 L axis
SVM3-12/12/20 A06B-6096-H302 N axis
SVM3-12/20/20 A06B-6096-H303 M and N axes
SVM3-20/20/20 A06B-6096-H304
L, M, and N
axes
SVM3-12/20/40 A06B-6096-H306 M axis
α series
servo amplifier module
SVM3-20/20/40 A06B-6096-H307 L and M axes
β series
servo amplifier unit
SVU-20 A06B-6093-H112
