0i Mate - MC Operators manual Page 467

Operators manual

Page of 872

/ 872

OPERATION

B–64144EN/01

4. AUTOMATIC OPERATION

443

By activating automatic operation during the DNC operation mode

(RMT), it is possible to perform machining (DNC operation) while a

program is being read in via reader/puncher interface, or remote buffer.

It is possible to select files (programs) saved in an external input/output

unit of a floppy format (such as Handy File) and specify (schedule) the

sequence and frequency of execution for automatic operation.

(see III–4.4)

To use the DNC operation function, it is necessary to set the parameters

related to the reader/punch interface in advance.

DNC OPERATION

1 Search for the program (file) to be executed.

2 Press the REMOTE switch on the machine operator’s panel to set

RMT mode, then press the cycle start switch. The selected file is

executed. For details of the use of the REMOTE switch, refer to the

relevant manual supplied by the machine tool builder.

PROGRAM CHECK O0001 N00020

O0010 ;

G92 G90 X100 Y200 Z50 ;

G00 X0 Y0 Z0 ;

G01 Z250 F1000

(RELATIVE) (DIST TO GO) G00 G94 G80

X 100.000 X 0.000 G17 G21 G98

Y 100.000 Y 0.000 G90 G49 G80

Z 0.000 Z 0.000 G22 G49 G67

A 0.000 A 0.000 B

C 0.000 C 0.000 H M

HD.T NX.T D M

F S M

ACT.F SACT REPEAT

RMT STRT MTN *** *** 21:20:05

[ ABS ] [ REL ] [ ] [ ] [ (OPRT) ]

D Program check screen

4.3

DNC OPERATION

Procedure
