OPERATION11. SETTING AND DISPLAYING DATA
B–64144EN/01
622
8 Pressing the [EXEC] operation soft key displays the group–unit
program list screen, listing all those programs whose name includes
the specified character string.
PROGRAM (NUM.) MEMORY (CHAR.)
USED: 60 3321
FREE: 2 429
O0020 (GEAR–1000 MAIN)
O0040 (GEAR–1000 SUB–1)
O0200 (GEAR–1000 SUB–2)
O2000 (GEAR–1000 SUB–3)
> _
EDIT **** *** *** *** 16:52:25
[ PRGRM ] [ DIR ] [ ] [ ] [ (OPRT) ]
PROGRAM DIRECTORY (GROUP) O0001 N00010
[Group–unit program list screen displayed
when a search is made for “GEAR–1000*”]
When the program list consists of two or more pages, the pages can be
changed by using a page key.
In the above example, the asterisk (*) must not be omitted. The asterisk
indicates an arbitrary character string (wild card specification).
“GEAR–1000*” indicates that the first nine characters of the target
program names must be “GEAR–1000,” followed by an arbitrary
character string. If only “GEAR–1000” is entered, a search is made only
for those CNC programs having the nine–character name “GEAR–1000.”
A question mark (?) can be used to specify a single arbitrary character.
For example, entering “????–1000” enables a search to be made for
programs having names which start with four arbitrary characters,
followed by “–1000”.
EXEC
Explanations
D * and ?
