4.INTERPOLATION FUNCTIONS PROGRAMMING B-63784EN/01

- 138 -

- Maximum cutting feedrate along each axis

With the conventional specification, the specified feedrate F during

NURBS interpolation is clamped to the minimum value of the

maximum cutting feedrate (parameter No. 1422) of each axis as

indicated by the expression below.

))(),(),(),(),(Min(

maxmaxmaxmaxmax

BFAFZFYFXFF ≤

So, when the maximum cutting feedrate of a rotation axis F

max

is small,

the specified feedrate F during NURBS interpolation may be clamped

to F

max

of the rotation axis, resulting in an increase in machining time.

This function changes the method of clamping the specified feedrate F

as described below.

The specified feedrate F is clamped so that the component of F along

each axis does not exceed the maximum cutting feedrate (parameter No.

1422) of each corresponding axis (Fig. 4.17.1(a)).

1 segment

F(0)

F(1)

F(t)

Fig. 4.17.1(a)

An example of NURBS interpolation using the five axes X, Y, Z, A,

and B is explained below.

Here, the feedrate F is represented by vector F(t) (where t changes from

0 to 1 in one segment). Let F

(t), F

(t), and F

(t) be the

components of the individual axes. Then, the following expression is

given:

))(),(),(),(),(()( tFtFtFtFtFtF

bazyx

= (t = 0 to 1 in one segment)

Then,

)(tFF =

At this time, F is clamped so that the following states are satisfied at all

times in the segment:

)()(

max

BFtF

AFtF

ZFtF

YFtF

XFtF

≤

In other words, the conditions below must be satisfied when the

clamped feedrate F is multiplied by the proportion of each axis

component (such as

)(
