B-63784EN/01 PROGRAMMING 14.COMPENSATION FUNCTION

- 541 -

- Compensation performed when θ

θθ

θ is approximately 0deg., 90deg., or 180deg.

When the included angle θ between V

Mn+1

and V

is regarded as 0deg.,

180deg., or 90deg., the compensation vector is created in a different

way. So, when creating an NC program, note the following points :

(1) Setting a variation range for regarding θ as 0deg., 180deg., or

90deg.

When the included angle (θ) between the tool vector (V

) and the

movement vector (V

) becomes approximately 0deg., 180deg., or

90deg., the system regards θ as 0deg., 180deg., or 90deg., then

creates a compensation vector which is different from the normal

compensation vector. The variation range used for regarding θ as

0deg., 180deg., and 90deg. is or in parameter 6115.

For example, suppose that the angle set in parameter 6115 is ∆θ.

(1) If 0 ≤ θ ≤ ∆θ, θ is regarded as 0deg.

∆θ

Mn+1

Fig.14.14.2 (i) Determination of θ

θθ

θ=0deg.

(2) If (180-∆θ) ≤ θ ≤ 180, θ is regarded as 180deg.

∆θ

Mn+1

Fig.14.14.2 (j) Determination of θ

θθ

θ=180deg.

(3) If (90-∆θ) ≤ θ ≤ (90+∆θ), θ is regarded as 90deg.

∆θ

Mn+1

∆θ

Mn+1

Fig.14.14.2 (k) Determination of θ

θθ

θ=90deg.
