B-63784EN/01 PROGRAMMING 10.TOOL FUNCTION (T FUNCTION)

- 249 -

Life values

A life value can be registered as either a time or frequency, by using bit

3 (LTM) of parameter No. 7400 or setting the corresponding count type

(with the Q command). The maximum values are as follows:

Table 10.2.2 (a) Life Count Types and Maximum Life Values

LTM (No.7400#3) Life count type Maximum life value

0 Frequency 99999999 times

1 Time 999 time units

When the count type is time, the units for the life value specified for

address L can be toggled between minutes and tenths of a second, using

bit 1 (FGL) of parameter No. 7403).

Table 10.2.2 (b) Life Value Units and Maximum Allowable Values for L

FGL

(No.7403#1)

Life value

units

Maximum

allowable

value for L

Example

0 Minutes 59940

L1000:

The life value is 1000 minutes.

Tenths of a

second

35964000

L1000:

The life value is 100 seconds.
