B-63784EN/01 PROGRAMMING 14.COMPENSATION FUNCTION

- 577 -

Examples

O300 is sample program 3.

In this example, each side, 100 mm long, of an equilateral triangle is

created with the B-axis set, respectively, to 0, 30 to 60, and 60 degrees.

O300 (Sample Program3) ;

N10 G55 ;

Gets the programming coordinate system ready

N20 G90 X50.0 Y-70.0 Z300.0 B0 C0 ;

Moves the tool to the initial position.

N30 G01 G43.4 H01 Z20.0 ;

Starts tool center point control.

Moves the tool to an approach position.

H01 is a tool compensation number.

N40 X28.868 Y-50.0 Z10.0 B30.0 ;

Set the height of the surface to be cut to 10.0 mm along the Z-axis.

N50 Y50.0 ;

N60 B45.0 C120.0 ;

N70 X-57.735 Y0 B60.0 C180.0 ;

Moves the tool along the X- and Y-axes while keeping the B- and C-axes

operating.

N80 C240.0 ;

N90 X28.868 Y-50.0 ;

N100 X50.0 Y-70.0 Z20.0 B0 C360.0 ;

Set the X, Y, and Z coordinates of the approach position.

Moves the rotary axes to the previous position.

N110 G49 Z300.0 ;

Cancels tool center point control.

Moves the tool to the initial position along the Z-axis.

N120 M30;
