B-63784EN/01 PROGRAMMING 14.COMPENSATION FUNCTION

- 543 -

If the previous compensation vector (V

Cn-1

) points in the same

direction ( -(V

× V

Tn-1

) × V

Tn-1

direction) as V

with respect to

Tn-1

, the current compensation vector (V

) is created so it points

in the -(V

Mn+1

× V

) ×V

direction.

Tool center path

(

after com

ensation

)

Pro

rammed

ath

Fig.14.14.2 (o) When θ

θθ

θ=90deg. Is Determined (2)

Limitation

- G41.2, G42.2, and G41.3 modes

G41.2, G42.2, G41.3, and G40 are continuous-state G codes that

belong to the same group. Therefore, the G41.2, G42.2, and G41.3

modes cannot exist at the same time.

- Canned cycle command and reference position return command

Specify a canned cycle command and reference position return

command in the compensation cancel mode (G40).

- Command that must not be specified in two or more successive blocks

In the compensation mode, never successively specify two or more

blocks that involve no movement. Blocks involving no movement

include :

- M05; M code output

- S21; S code output

- G04X1000; Dwell

- G22X100000; Machining area setting

- G10P01R100; Offset value setting

- G90;,O10;,N20; Block containing no move command

- Reset

Resetting the system in a compensation mode (G41.2, G42.2, or G41.3)

always results in the cancellation mode (G40).
