AI (NANO) HIGH PRECISION CONTOUR CONTROL Additional Manual Page 29

Additional Manual
Title
No.
FANUC Series 16i/18i -MA/MB
AI High Precision Contour Control
FANUC Series 16i -MA/MB
AI Nano High Precision Contour Control
A-78435E
Page
28/
36
Newly registered

Ver Date Design Description
01 01.03.16
Hosokawa
8456 Override for area 2 in deceleration based on AI High Precision Contour
Control cutting load
8457 Override for area 3 in deceleration based on AI High Precision Contour
Control cutting load
8458 Override for area 4 in deceleration based on AI High Precision Contour
Control cutting load
[Input type] Parameter input
[Data type] Word type
[Unit of data] %
[Valid data range] 1 - 100
With the deceleration function based on AI High precision Contour Control cutting
load, a specified override can be applied according to the Z-axis falling angle.
A feedrate found from other conditions is multiplied by the override value of an
area to which the falling angle
Į
belongs. Note, however, that no parameter is
available for area 1, and an override of 100% is used at all times.
Area1 0
°
≤
θ
<30
°
Area2 30
°
≤
θ
<45
°
Area3 45
°
≤
θ
<60
°
Area4 60
°
≤
θ
≤
90
°
