AI (NANO) HIGH PRECISION CONTOUR CONTROL Additional Manual Page 37
Additional Manual
Title
No.
FANUC Series 16i/18i -MA/MB
AI High Precision Contour Control
FANUC Series 16i -MA/MB
AI Nano High Precision Contour Control
A-78435E
Page
36/
36
Newly registered
Ver Date Design Description
01 01.03.16
Hosokawa
Item Specifications Note
Miscellaneous/spindle functions
Miscellaneous function The AI high precision contour control mode or the AI NANO high
precision contour control mode is automatically canceled once and
the buffering is inhibited if this function is used in the AI high
Precision Contour Control mode or in the AI high Precision
Contour Control mode.
2nd. Auxiliary function The AI high precision contour control mode or the AI NANO high
precision contour control mode is automatically canceled once and
the buffering is inhibited if this function is used in the AI high
Precision Contour Control mode or in the AI high Precision
Contour Control mode.
1 block plural M commands The AI high precision contour control mode or the AI NANO high
precision contour control mode is automatically canceled once and
the buffering is inhibited if this function is used in the AI high
Precision Contour Control mode or in the AI high Precision
Contour Control mode.
It is possible to command up to 3.
Spindle speed function The AI high precision contour control mode or the AI NANO high
precision contour control mode is automatically canceled once and
the buffering is inhibited if this function is used in the AI high
Precision Contour Control mode or in the AI high Precision
Contour Control mode.
Tool functions
Tool functionT8 The AI high precision contour control mode or the AI NANO high
precision contour control mode is automatically canceled once and
the buffering is inhibited if this function is used in the AI high
Precision Contour Control mode or in the AI high Precision
Contour Control mode.
Tool length compensation G43
Cutter compensation G38,G39,G40,G41,G42 The buffering is inhibited when the command which automatically
cancel AI high precision contour control mode or AI NANO high
precision contour control mode is used.
So the tool offset vector is held.
3-dimensional tool compensation G41.2,G42.2
G41.3
The command which automatically cancel AI high precision
contour control mode or AI NANO high precision contour control
mode can not be used.
However M,S,T and B command can be used without the
command that move some axes. In this case, the offset vector is
held because the buffering is inhibited.
Tool axis direction tool length
compensation
G43.1 The command which automatically cancel AI high precision
contour control mode or AI NANO high precision contour control
mode can not be used.
However M,S,T and B command can be used without the
command that move some axes. In this case, the offset vector is
held because the buffering is inhibited.
Tool center point control G43.4,G43.5 The command which automatically cancel AI high precision
contour control mode or AI NANO high precision contour control
mode can not be used.
However M,S,T and B command can be used without the
command that move some axes. In this case, the offset vector is
held because the buffering is inhibited.
Rotary table dynamic fixture offset G54.2 The mode of AI high precision contour control or of AI NANO
high precision contour control is permitted to change ON and OFF
in rotary table dynamic fixture offset mode by setting the
parameter. The alarm (P/S5012) occurs if the mode of AI high
precision contour control or of AI NANO high precision contour
control is changed in rotary table dynamic fixture offset mode
when the parameter is not set.
