AI (NANO) HIGH PRECISION CONTOUR CONTROL Additional Manual Page 30

Additional Manual
Title
No.
FANUC Series 16i/18i -MA/MB
AI High Precision Contour Control
FANUC Series 16i -MA/MB
AI Nano High Precision Contour Control
A-78435E
Page
29/
36
Newly registered

Ver Date Design Description
01 01.03.16
Hosokawa
#7 #6 #5 #4 #3 #2 #1 #0
8459 OVR
[Input type] Parameter input
[Data type] Bit
# 3
# 3 # 3
# 3 OVR
OVROVR
OVR In look-ahead acceleration/deceleration before interpolation and AI High
Precision Contour Control :
0: Override is disabled for deceleration functions such as deceleration based on
feedrate difference and deceleration based on acceleration rate.
1: Override is enabled for deceleration functions such as deceleration based on
feedrate difference and deceleration based on acceleration rate.
This function allows the following feedrates to be overridden:
- Feedrate decelerated by deceleration based on feedrate difference in look-ahead
acceleration/deceleration before interpolation
- Feedrate decelerated by deceleration based on acceleration rate in AI High
Precision Contour Control.
- Feedrate decelerated by deceleration based on acceleration rate in circular
interpolation
- Feedrate decelerated by acceleration clamp in involute interpolation
- Minimum feedrate for deceleration based on acceleration rate in AI High Precision
Contour Control and circular interpolation
- Maximum feedrate of AI High Precision Contour Control Even when the feedrate
is overridden by this function, the resulting
feedrate does not exceed the maximum cutting feedrate (parameter No. 1422 or
No.1430 or No.1432).
