AI (NANO) HIGH PRECISION CONTOUR CONTROL Additional Manual Page 5

Additional Manual
Title
No.
FANUC Series 16i/18i -MA/MB
AI High Precision Contour Control
FANUC Series 16i -MA/MB
AI Nano High Precision Contour Control
A-78435E
Page
4/
36
Newly registered

Ver Date Design Description
01 01.03.16
Hosokawa
Functions enabled
In AI High Precision Countour Control mode, the following functions are
enabled:
(1) Linear acceleration/deceleration before interpolation or bell-shaped
acceleration/deceleration before interpolation
(Acceleration change time constant type)
(2) Deceleration function based on feedrate differences at corners
(3) Advanced feed-forward function
(4) Feedrate determination based on acceleration on each axis
(5) Deceleration function based on Z-axis fall angle
(6) 200-block multi-buffer function
