AI (NANO) HIGH PRECISION CONTOUR CONTROL Additional Manual Page 33

Additional Manual
Title
No.
FANUC Series 16i/18i -MA/MB
AI High Precision Contour Control
FANUC Series 16i -MA/MB
AI Nano High Precision Contour Control
A-78435E
Page
32/
36
Newly registered

Ver Date Design Description
01 01.03.16
Hosokawa
19510 Parameter 2 for determining a linear acceleration/deceleration before
interpolation
[Input type] Parameter input
[Data type] word type
[Unit of data] msec
[Valid data range] 0 - 1000
This parameter specifies the time required until the speed specified
n parameter 1(No.8400) is achieved.
When the bell–shaped acceleration/deceleration before
interpolation is used, the data specified in parameter 1 and
parameter 2 determines the maximum acceleration of bell–shaped
acceleration/deceleration before look ahead interpolation.
The function for linear acceleration/deceleration before
interpolation is canceled when either parameter No.8400 or
No.19510 is set to 0 in all axis.
Set for acceleration time up to maximum speed to become 1
second or less.
If the allowable acceleration for one axis is twice as large as that
for another or more, the feedrate may temporarily reduce around
corners where the direction to travel changes suddenly.
Note
NOTE
1 If the permissible acceleration set for one axis is two or
more times greater than that set for another, the feedrate
may decrease temporarily at those corners where the
travel direction changes abruptly.
2 If the machine lock signal is turned on during travel in
look-ahead acceleration/deceleration before interpolation
mode, the machine enters the machine lock state after the
end of deceleration.
3 If there is a block with no travel or a one-shot G code
command such as G04 in look-ahead
acceleration/deceleration before interpolation mode,
deceleration is performed for a stop in the preceding
block.
4 If the dry run signal changes from "0" to "1" or from "1"
to "0" during travel on an axis, acceleration/deceleration
is performed to achieve the prescribed feedrate without
deceleration to feedrate 0.
The function for deceleration with the feedrate difference
at a corner is effective even during dry run.
