I/O LINK II Connection manual Page 159

Connection manual
B-62714EN/04 CONNECTION 6.Power Mate i-D/H
- 147 -
NOTE
1 If I/O Link-II slave board B and I/O Link-II board B of
the CNC are placed on the same line, the global I/O
transfer function does not operate normally on the
I/O Link-II board of the Power Mate i. (The DI/DO
data transfer function can operate normally.)
2 If I/O Link-II slave board B and I/O Link-II board
B1/B2 of the CNC are on the same line, the global
I/O transfer function does not operate normally on
the I/O Link-II board of the Power Mate-D/F/H. (The
DI/DO data transfer function can operate normally.)
Differences from the I/O Link-II board of Power Mate-D/F/H
The I/O Link-II slave board and I/O Link-II slave board B differ from
the I/O Link-II board of Power Mate-D/H as described below.
(1) No relay terminal unit and branch cable are required.
(2) A 5-pin communication connector is used.
(3) No built-in DI/DO is available on the board. (The DI/DO:32/24
built into the main unit can be used.)
(4) The I/O Link-II slave board and I/O Link-II slave board B are CE
mark-compliant.
