I/O LINK II Connection manual Page 74

Connection manual
2.LCD-MOUNTED TYPE 16i/18i/21i-A, Power Mate i-D/H OPERATION B-62714EN/04
- 62 -
Setting items
Table III-2-4
Item Description
STATION NO.
Station number of the slave station.
Setting range: 1 to 31(Note)
BAUD-RATE
Communication speed.
Setting range: 0 to 3
0: 1.0 Mbps
1: 500 kbps
2: 250 kbps
3: 125 kbps
Two methods of setting are available:
- Input using numeric keys
- Input by soft key selection
(Displayed when the cursor is placed on this
parameter)
STATUS ADDRESS
Start address of an area for storing communication
status.
Setting range: R area of the PMC
The storing of communication status can be disabled
by selecting the soft key [DISABLE] displayed when
the cursor is placed on this parameter.
When the storing of communication status is
disabled, "----" is displayed.
OPTION1 Not used
OPTION2 Not used
DI/DO MAP MODE
Determines the method of allocating a DI/DO data
area.
Setting: 0, 1
0: DI/DO data transfer function
A DI data area and DO data area are allocated for one
station.
1: Global I/O transfer function
A DI data area is allocated for the number of stations
set in MAX SLAVE NO. plus 1, and a DO data area is
allocated for one station.
Two methods of setting are available: input using
numeric keys and input by soft key selection.
(Displayed when the cursor is placed on this
parameter)
MAX SLAVE NO.
Maximum slave number that takes in DO data when
global I/O transfer is performed.
Setting range: 1 to 31
When DI/DO data transfer (NORMAL) is selected in
DI/DO MAP MODE, this parameter is disabled and "--
" is displayed.
DO ADDRESS
DO data area start address.
Setting range: R area of the PMC
DO SIZE
DO data area size.
Setting range: 0 to 128(Caution)
(Unit: Bytes)
When DO is not used, set 0.
