Series 0i - TA Operators manual Page 218

Operators manual

Page of 714

/ 714

PROGRAMMING14. COMPENSATION FUNCTION

B–63504EN/01

194

Imaginary tool nose numbers 0 and 9 are used when the tool nose center

coincides with the start position. Set imaginary tool nose number to

address OFT for each offset number.

Bit 7 (WNP) of parameter No. 5002 is used to determine whether the tool

geometry offset number or the tool wear offset number specifies the

direction of the virtual tool nose for tool nose radius compensation.

Imaginary tool nose number 0 to 9

Virtual tool nose directions 1 to 8 can be used only in the G18 (Z–X) plane.

For virtual tool nose 0 or 9, compensation is applied in both the G17 and

G19 planes.

Tool nose radius compensation value

(Tool nose radius value)

Limitations

D Plane selection

14.2.3

Offset Number and

Offset Value

Explanations

D Offset number and offset

value
