Series 0i - TA Operators manual Page 393

Operators manual
OPERATION
B–63504EN/01
2. OPERATIONAL DEVICES
369
Soft key transition triggered by the function key
in the HNDL, JOG, or REF mode
PROG
[(OPRT)] [BG–EDT][PRGRM]
Program display
PROGRAM SCREEN
Current block display screen
[(OPRT)] [BG–EDT][CURRNT]
Next block display screen
[(OPRT)] [BG–EDT][NEXT]
Program restart display screen
[(OPRT)] [BG–EDT][RSTR]
See “When the soft key [BG–EDT] is pressed”
See “When the soft key [BG–EDT] is pressed”
See “When the soft key [BG–EDT] is pressed”
See “When the soft key [BG–EDT] is pressed”
PROG
Soft key transition triggered by the function key
in the TJOG or THDL mode
PROG
[(OPRT)]
[BG–EDT
][PRGRM]
Program display
PROGRAM SCREEN
(Address)
(Address)
[SRH↓]
[SRH↑]
(O number)
[REWIND]
[(OPRT)] [BG–EDT]
(O number)
[O SRH]
[LIB]
Program directory display
Return to the program
See “When the soft key [BG–EDT] is pressed”
See “When the soft key [BG–EDT] is pressed”
[O SRH]
Return to the program
PROG
