OPERATION

B–63504EN/01

11. SETTING AND DISPLAYING DATA

559

This section describes the screens displayed by pressing function key

PROG

in MEMORY or MDI mode.The first four of the following screens

display the execution state for the program currently being executed in

MEMORY or MDI mode and the last screen displays the command values

for MDI operation in the MDI mode:

11.2.1 Program contents display screen

11.2.2 Current block display screen

11.2.3 Next block display screen

11.2.4 Program check screen

11.2.5 Program screen for MDI operation

Function key

PROG

can also be pressed in MEMORY mode to display the

program restart screen and scheduling screen.

See Section III–4.3 for the program restart screen.

See Section III–4.4 for the scheduling screen.

11.2

SCREENS DISPLAYED

BY FUNCTION KEY pr

(IN MEMORY MODE OR

MDI MODE)

PROG
