OPERATION12. GRAPHICS FUNCTION

B–63504EN/01

618

Since the graphic drawing is done when coordinate value is renewed

during automatic operation, etc., it is necessary to start the program by

automatic operation. To execute drawing without moving the machine,

therefore, enter the machine lock state.

Pressing the

[REVIEW] soft key on the graphic screen deletes tool paths

on it. Setting the graphic parameter as AUTO ERASE (A) = 1 specifies

that when automatic operation is started at reset, program execution

begins after the previous drawing is erased automatically (AUTO ERASE

= 1).

When necessary to display a part of a program, search the starting block

to be drawn by the sequence number search, and set the sequence number

of the end block to the PROGRAM STOP N= of the graphic parameter

before starting the program under cycle operation mode.

The tool path is shown with a dashed line (

) for rapid traverse and

with a solid line (

) for cutting feed.

The displayed drawing is indicated with coordinates in a work coordinate

system.

The machine zero point is indicated with mark.

Even if the screen is switched to a non–drawing screen, drawing

continues. When the drawing screen is displayed again, the entire

drawing appears (no parts are missing).

In case the feed rate is considerably high, drawing may not be executed

correctly, decrease the speed by dry–run, etc. to execute drawing.

After a graphic parameter is changed, the

[REVIEW] soft key must be

pressed to initialize the graphic screen. Otherwise, the change to the

graphic parameter is not reflected correctly.

The coordinate axis names are fixed to X or Z.

If the WORK and DIAMETER graphic parameters are not set correctly,

the drawing cannot be magnified. To reduce a drawing, specify a negative

value for the SCALE graphic parameter.

D Executing drawing only

D Deleting the previous

drawing

D Drawing a part of a

program

D Drawing using dashed

lines and solid lines

D Displaying coordinates

D Displaying the machine

zero point

D Switching from a

drawing screen to

another screen

Restrictions

D Feedrate

D Changing the graphic

parameters during

automatic operation

D Coordinate axis names

D Zooming drawings
