Series 0i - TA Operators manual Page 687

Operators manual

Page of 714

/ 714

APPENDIX

B–63504EN/01

G. ALARM LIST

663

Number ContentsMessage

023 ILLEGAL RADIUS COMMAND In circular interpolation by radius designation, negative value was

commanded for address R. Modify the program.

028 ILLEGAL PLANE SELECT In the plane selection command, two or more axes in the same direc-

tion are commanded.

Modify the program.

029 ILLEGAL OFFSET VALUE The offset values specified by T code is too large.

Modify the program.

030 ILLEGAL OFFSET NUMBER The offset number in T function specified for tool offset is too large.

Modify the program.

031 ILLEGAL P COMMAND IN G10 In setting an offset amount by G10, the offset number following ad-

dress P was excessive or it was not specified.

Modify the program.

032 ILLEGAL OFFSET VALUE IN G10 In setting an offset amount by G10 or in writing an offset amount by

system variables, the offset amount was excessive.

033 NO SOLUTION AT NRC A point of intersection cannot be determined for tool nose radius com-

pensation. Modify the program.

034 NO CIRC ALLOWED IN ST–UP

/EXT BLK

The start up or cancel was going to be performed in the G02 or G03

mode in tool nose radius compensation. Modify the program.

035 CAN NOT COMMANDED G31 Skip cutting (G31) was specified in tool nose radius compensation

mode. Modify the program.

037 CAN NOT CHANGE PLANE IN NRC The offset plane is switched in tool nose radius compensation.

Modify the program.

038 INTERFERENCE IN CIRCULAR

BLOCK

Overcutting will occur in tool nose radius compensation because the

arc start point or end point coincides with the arc center.

Modify the program.

040 INTERFERENCE IN G90/G94

BLOCK

Overcutting will occur in tool nose radius compensation in canned

cycle G90 or G94. Modify the program.

041 INTERFERENCE IN NRC Overcutting will occur in tool nose radius compensation.

Modify the program.

046 ILLEGAL REFERENCE RETURN

COMMAND

Other than P2, P3 and P4 are commanded for 2nd, 3rd and 4th refer-

ence position return command.

053 TOO MANY ADDRESS

COMMANDS

Character after a comma(“,”) is not C or R in direct drawing dimen-

sions programming. Another possible cause is that a comma (,) was

specified in a method in which a comma must not be specified (pa-

rameter No.3405#4 = 1). Modify the program.

056 NO END POINT & ANGLE IN

CHF/CNR

Neither the end point nor angle is specified in the command for the

block next to that for which only the angle is specified (A).

Modify the program.

057 NO SOLUTION OF BLOCK END Block end point is not calculated correctly in direct dimension drawing

programming.

Modify the program.

058 END POINT NOT FOUND Block end point is not found in direct dimension drawing program-

ming.

Modify the program.

059 PROGRAM NUMBER NOT FOUND In an external program number search or external workpiece number

search, a specified program number was not found. Otherwise, a

program specified for searching is being edited in background pro-

cessing. Check the program number and external signal. Or discon-

tinue the background editing.

060 SEQUENCE NUMBER NOT FOUND Commanded sequence number was not found in the sequence num-

ber search. Check the sequence number.

061 ADDRESS P/Q NOT FOUND IN

G70–G73

Address P or Q is not specified in G70, G71, G72, or G73 command.

Modify the program.
