Series 0i - TA Operators manual Page 255

Operators manual

Page of 714

/ 714

PROGRAMMING

B–63504EN/01

14. COMPENSATION FUNCTION

231

Tool nose radius compensation is not performed for commands input

from the MDI.

However, when automatic operation using absolute commands is

temporarily stopped by the single block function, MDI operation is

performed, then automatic operation starts again, the tool path is as

follows :

In this case, the vectors at the start position of the next block are translated

and the other vectors are produced by the next two blocks. Therefore,

from next block but one, tool nose radius compensation is accurately

performed.

’

Command

for MDI

When position P

, P

, and P

are programmed in an absolute command,

tool is stopped by the single block function after executing the block from

to P

and the tool is moved by MDI operation. Vectors V

and V

are translated to V

’ and V

’ and offset vectors are recalculated for the

vectors V

and V

between block P

–P

and P

–P

However, since vector V

is not calculated again, compensation is

accurately performed from position P

14.3.7

Input Command from

MDI
