  2. FANUC Series 16i/160i

FANUC Series 16i/160i Additional Manual Page 12

Additional Manual
A-78075E
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/160i –L
Laser maintenance screen function
Specifications
2000.03.06
12/21
Sheet Sheet
M.Sato K.Suzuki
05 2001.08.23 M.Sato Change all page. K.Suzuki
06 2001.10.11 M.Sato Change page 10. K.Suzuki
07 2003.12.04 M.Sato Change all pages. K.Suzuki
08 2003.12.19 M.Sato Change page 4,17. K.Suzuki
09 2004.06.04 M.Sato Change page 14. K.Suzuki
10 2004.06.09 M.Sato Change page 13. K.Suzuki
11 2005.02.23 M.Sato Change all pages.
2.8 Operation of leak check
It is possible to set parameters for leak check and confirm leak check result by leak check
screen.
Pushing soft-key [leak] makes displaying leak check screen.
Switching off gas control start signal (G222#6) after setting parameters for leak check causes
starting leak check.
Please refer to specification (A-78037) of leak check function in detail.
2.8.1 Settable or referable data
The following data is displayed in leak check screen.
• Switching bit to select leak check enable or disable
• Judgment time for leak check
• Status
• Time remaining
• Leak check result
(1) Switching bit to select leak check enable or disable
Status of parameter No.15153#0 is displayed and it is possible to set the parameter in leak
check screen.
0 : Leak check disable
1 : Leak check enable
(2) Leak check judgment time
Setting value of leak check judgment time (parameter No.15154) is displayed and it is
possible to input a value to the parameter in the screen.
(3) Status
The status of leak checks operation is displayed. The following contents are displayed.
• STAND BY
• GAS PRES CHECK 1ST
• LAS PRES CHECK 2ND
• GAS PRES CHECK 3RD
• GAS PRES CHECK 4TH
(4) Time remaining
The estimated time to leak check end is displayed when all the valves are shut after
completion of evacuation.
The displayed time is deducted by passage time.
The displayed time is not guaranteed because it is rough estimated.
(5) Leak check result
