FANUC Series 16i/160i Additional Manual Page 4

Additional Manual
A-78075E
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/160i –L
Laser maintenance screen function
Specifications
2000.03.06
4/21
Sheet Sheet
M.Sato K.Suzuki
05 2001.08.23 M.Sato Change all page. K.Suzuki
06 2001.10.11 M.Sato Change page 10. K.Suzuki
07 2003.12.04 M.Sato Change all pages. K.Suzuki
08 2003.12.19 M.Sato Change page 4,17. K.Suzuki
09 2004.06.04 M.Sato Change page 14. K.Suzuki
10 2004.06.09 M.Sato Change page 13. K.Suzuki
11 2005.02.23 M.Sato Change all pages.
2 Specification
2.1 Display maintenance screens
PRM No.15160#0(MNT) should be set to 1 in order to display Laser maintenance screens.
2.2 Display of power calibration coefficient history
2.2.1 Logging power calibration coefficients
When power calibration works, power calibration coefficient, RF voltage No.1 and date are
logged after calculating power calibration coefficient.
Special operation (parameter setting etc.) is not needed to log the power calibration
coefficient. The data are logged automatically.
30 Power calibration coefficients can be logged. If data are over 30, the oldest data are
deleted and new data are logged.
2.2.2 Reference of logged power calibration coefficients
Push soft-key [PW.OFS], and screens for power calibration coefficient history are displayed.
There are 3 pages for the screens and 10 data are shown every page. Newer data are shown
upper of screen. In other word, the newest data are shown at No.1 of page 1.
Push Page-key on MDI panel to change page of the screens.
The logged data cannot be edited.
[Screens for power calibration coefficient history]
3 pages can be displayed by page-key on MDI panel.
[HISTORY OF POWER CALIB. COE.] 1/3
No CLB RFV1 SET DATE
1 1101 1421 1999.05.26 10:38:40
2 1098 1419 1999.05.25 09:31:15
3 1024 1422 1999.05.24 10:11:13
4 **** **** ****.**.** **.**.**
5 **** **** ****.**.** **.**.**
6 **** **** ****.**.** **.**.**
7 **** **** ****.**.** **.**.**
8 **** **** ****.**.** **.**.**
9 **** **** ****.**.** **.**.**
10 **** **** ****.**.** **.**.**
