FANUC Series 16i/160i –L
Laser maintenance screen function
Specifications
2000.03.06
13/21
Sheet Sheet
M.Sato K.Suzuki
05 2001.08.23 M.Sato Change all page. K.Suzuki
06 2001.10.11 M.Sato Change page 10. K.Suzuki
07 2003.12.04 M.Sato Change all pages. K.Suzuki
08 2003.12.19 M.Sato Change page 4,17. K.Suzuki
09 2004.06.04 M.Sato Change page 14. K.Suzuki
10 2004.06.09 M.Sato Change page 13. K.Suzuki
11 2005.02.23 M.Sato Change all pages.
Laser gas pressure 1 to 4 (Diagnose No.954 to 957) read during leak check are displayed.
The data are only displayed and cannot be reset or operated.
The data are displayed by Torr and kilo-Pascal (kPa).
[Leak check screen]
[ LEAK CHECK ]
LEAK CHECK (1:ON 0:OFF) [*]
LEAK JUDGEMENT TIME [*****]SEC
STATUS STAND BY
TIME REMAINING ****** SEC
RESULT
1ST **** TORR **** KPA
2ND **** TORR **** KPA
3RD **** TORR **** KPA
4TH **** TORR **** KPA
>
Previous page
Next page
