FANUC Series 16i/160i Additional Manual Page 16

Additional Manual
A-78075E
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/160i –L
Laser maintenance screen function
Specifications
2000.03.06
16/21
Sheet Sheet
M.Sato K.Suzuki
05 2001.08.23 M.Sato Change all page. K.Suzuki
06 2001.10.11 M.Sato Change page 10. K.Suzuki
07 2003.12.04 M.Sato Change all pages. K.Suzuki
08 2003.12.19 M.Sato Change page 4,17. K.Suzuki
09 2004.06.04 M.Sato Change page 14. K.Suzuki
10 2004.06.09 M.Sato Change page 13. K.Suzuki
11 2005.02.23 M.Sato Change all pages.
2.9.2Command of running beam internally with shutter closed
It is possible to command running beam internally with shutter closed in laser tuning screen.
Pushing soft-key [(OPRT)] in laser tuning screen makes displaying soft-key [DISCH.] and
[CAN]. (Refer to figure on the previous page.)
Pushing soft-key [DISCH.] with satisfying following conditions causes running beam
internally with shutter closed
• Parameter No.15160#1(MDS) is set 1.
• Laser sequence No. (Diagnose No.908) is 30.
• Shutter is closed.
• Beam output is not commanded.
• Laser alarm does not occur.
Pushing soft-key [CAN] during running beam internally causes stopping beam.
note )
1) The beam output condition is determined only by the command
power, the pulse frequency, and the pulse duty in the laser tuning
screen in case of commanding the running beam internally with
shutter closed on the laser tuning screen.
The power calibration coefficient, the power feedback and each
override-command are invalid.
2) The running beam internally does not stop even if the switch of the
reset and BEAM OFF is pushed in case of commanding the running
beam internally on the laser tuning screen.
And the running beam internally stops when the switch of the
emergency stop and HV-OFF is pushed.
