FANUC Series 16i/160i –L
Laser maintenance screen function
Specifications
2000.03.06
9/21
Sheet Sheet
M.Sato K.Suzuki
05 2001.08.23 M.Sato Change all page. K.Suzuki
06 2001.10.11 M.Sato Change page 10. K.Suzuki
07 2003.12.04 M.Sato Change all pages. K.Suzuki
08 2003.12.19 M.Sato Change page 4,17. K.Suzuki
09 2004.06.04 M.Sato Change page 14. K.Suzuki
10 2004.06.09 M.Sato Change page 13. K.Suzuki
11 2005.02.23 M.Sato Change all pages.
2.5 Display of history for laser alarms and warnings
The history of only Laser alarms and warnings are displayed.
Following data can be logged 50 in all. The oldest datum is deleted and new one is logged in
case of exceeding 50 items.
• Laser warning
• Laser alarm
2.5.1 Laser warning
Information for maintenance is logged as laser warning.
The information is only logged. So, message or PMC signal is not output.
Laser warning is only following information now.
Warning No. 0001
Message PURGE INCOMPLETE
Meaning CNC is powered off before copletng purge.
2.5.2 Reference of logged laser alarms
Pushing soft-key [L ALARM] makes displaying laser alarm history screen (9 inch CRT
image).
5 Laser alarms and warnings are logged in 1 page and total 10 pages are included.
“PAGE↑” and “PAGE↓” keys on MDI panel should be used to change the pages.
Logged data cannot be deleted.
[Laser alarm history screen]
[ LASER ALARM HISTORY ] 01/10
03/11/20 10:23:22
ALM 4100 INVERTER 1
03/11/01 08:10:53
ALM 4105 TURBO TEMP. 1
03/10/24 20:30:14
WNG 0001 PURGE INCOMPLETE
03/10/15 17:03:02
ALM 4077 ABSORBER TEMP.
03/10/07 13:59:11
ALM 4000 P/S ALARM
