FANUC Series 16i/160i –L
Laser maintenance screen function
Specifications
2000.03.06
20/21
Sheet Sheet
M.Sato K.Suzuki
05 2001.08.23 M.Sato Change all page. K.Suzuki
06 2001.10.11 M.Sato Change page 10. K.Suzuki
07 2003.12.04 M.Sato Change all pages. K.Suzuki
08 2003.12.19 M.Sato Change page 4,17. K.Suzuki
09 2004.06.04 M.Sato Change page 14. K.Suzuki
10 2004.06.09 M.Sato Change page 13. K.Suzuki
11 2005.02.23 M.Sato Change all pages.
2.13 PMC signals
Laser maintenance
request signal
LSMNT< F226#0>
[Classification] Output signal
[Function] Item that working time is over limit time exists or not.
[Operation] 0 : Not exist.
1 : Exist.
Turbo blower overhaul
request signal
LSMTM< F226#1>
[Classification] Output signal
[Function] Request signal for turbo-blower overhaul.
[Operation] Any of working time “Blower 1 overhaul” to “Blower 4 overhaul” is over limit
time.
Turbo blower oil exchange
request signal
LSMTO< F226#2>
[Classification] Output signal
[Function] Request signal for turbo-blower oil change.
[Operation] Working time “Blower oil” is over limit time on working time screen.
Inner mirror cleaning
request signal
LSMIM< F226#3>
[Classification] Output signal
[Function] Request signal for inner mirror cleaning.
[Operation] Any of working time “Output mirror”, ”Folding mirror”, “Rear mirror”, or
“Shutter mirror” is over limit time.
Optical compensation unit mirror
cleaning request signal
LSMBM< F226#4>
[Classification] Output signal
[Function] Request signal for optical compensation unit mirror cleaning.
[Operation] Any of working time “Optical compensation mirror 1” or “Optical compensation
mirror 2” is over limit time.
