FANUC Series 16i/160i –L
Laser maintenance screen function
Specifications
2000.03.06
17/21
Sheet Sheet
M.Sato K.Suzuki
05 2001.08.23 M.Sato Change all page. K.Suzuki
06 2001.10.11 M.Sato Change page 10. K.Suzuki
07 2003.12.04 M.Sato Change all pages. K.Suzuki
08 2003.12.19 M.Sato Change page 4,17. K.Suzuki
09 2004.06.04 M.Sato Change page 14. K.Suzuki
10 2004.06.09 M.Sato Change page 13. K.Suzuki
11 2005.02.23 M.Sato Change all pages.
2.10 Input and output of saved maintenance data
The saved data can be output to memory card or other external device via reader puncher
interface (RS-232C). And some kind of the data can be input.
The format of the output data is almost the same as the display of CRT, but the comment is
output only in English.
The data that can be input and output are as follows.
Data Output Input
Power calibration coefficient history data OK NG
Parts running time data OK NG
Alarm related to discharging data OK NG
Laser alarm history data OK NG
Power feedback table data OK OK
2.10.1 How to output the data to memory card with operating the each maintenance screen
(1) The I/O channel should be switched to the memory card by setting 4 to parameter
No.0020.
(2) After switching the operation mode to "EDIT", data are output by pushing the soft-key
as follows. [OPER] -> [PUNCH] -> [EXEC]
The output data are saved as a text file and the file is named as follows.
Data File name
Power calibration coefficient history data PW-OFS.DAT
Parts running time data P-ACT.DAT
Alarm related to discharging data LSALM-H.DAT
Laser alarm history data LSRALMHT.DAT
Power feedback table data LPPFBDT.DAT
2.10.2 Data Input from and output to external device via reader puncher interface with
operating the each maintenance screen
(1) HANDY-FILE should be connected with CNC.
And HANDY-FILE should be communicated with CNC by setting communication
conditions such as I/O channel, baud rate, etc to CNC parameters.
(2) Select the screen of desired data and push soft-key [(OPRT)] after switching the
operation mode to "EDIT",.
(3) Push soft-key [PUNCH] in case of data output and push soft-key [READ] in case of data
input.
And push soft-key [EXEC], then data can be output or input.
