FANUC Series 16i/160i Additional Manual Page 21

Additional Manual
A-78075E
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/160i –L
Laser maintenance screen function
Specifications
2000.03.06
21/21
Sheet Sheet
M.Sato K.Suzuki
05 2001.08.23 M.Sato Change all page. K.Suzuki
06 2001.10.11 M.Sato Change page 10. K.Suzuki
07 2003.12.04 M.Sato Change all pages. K.Suzuki
08 2003.12.19 M.Sato Change page 4,17. K.Suzuki
09 2004.06.04 M.Sato Change page 14. K.Suzuki
10 2004.06.09 M.Sato Change page 13. K.Suzuki
11 2005.02.23 M.Sato Change all pages.
Chiller cooling water exchange
request signal
LSMCW< F226#5>
[Classification] Output signal
[Function] Request signal for chiller coolant change.
[Operation] Working time “Chiller coolant” is over limit time.
2.14 Signal address
#7 #6 #5 #4 #3 #2 #1 #0
F0226 LSMCW LSMBM LSMIM LSMTO LSMTM LSMNT
3 Limitation
The maintenance data used for this function are memorized in memory area that is back-up
with battery.
So, the data are lost if CNC is powered-off in case of battery Lost.
And the data are lost when memory area is all cleared.
• The maintenance data used for this function are memorized in memory area that is
backed-up with battery. So, the data are lost if CNC is powered-off in case of battery
lost. And the data are lost when the memory area is cleared.
• Depending on edition of system software, the screens are displayed only in English and
Japanese. So, the screens are displayed in English except for select Japanese.
4 Applicable series
FS16i/160i-LA/LPA FS16i/160i-LB/LPB
B8F1 B8F3 B8F5 B8F6 B8H1 B8H5
Screens for power calibration coefficient history 15 02 05 01 01 02
Screens for parts working time 15 02 05 01 01 02
History screen of alarm related to electrical discharge 16 03 05 02 01 02
Screens for laser alarm history --- 08 --- --- 04 02
Screens for pulse power feedback --- --- --- --- 03 02
Screen for measurement of power sensor time constant --- 08 --- --- 03 02
Screen for leak check --- --- --- --- 07 02
Screen for laser tuning --- 08 --- --- 03 02
note )
The screen might be displayed by the old versions not applied.
However, correct data might not be displayed in old versions.
Please use this function after confirming the above-mentioned
number of versions.
