FANUC Series 16i/160i –L
Laser maintenance screen function
Specifications
2000.03.06
19/21
Sheet Sheet
M.Sato K.Suzuki
05 2001.08.23 M.Sato Change all page. K.Suzuki
06 2001.10.11 M.Sato Change page 10. K.Suzuki
07 2003.12.04 M.Sato Change all pages. K.Suzuki
08 2003.12.19 M.Sato Change page 4,17. K.Suzuki
09 2004.06.04 M.Sato Change page 14. K.Suzuki
10 2004.06.09 M.Sato Change page 13. K.Suzuki
11 2005.02.23 M.Sato Change all pages.
2.12 Parameter
#7 #6 #5 #4 #3 #2 #1 #0
15160 MDS MNT
[Data Type] Bit
MNT Specifies whether laser maintenance screens are enabled or disabled.
0: Disabled.
1: Enabled.
Even if the screen is not displayed, the storage of power calibration coefficients and the
totaling of the operation time are performed, so that the screen can be displayed for
confirmation when needed.
MDS Using mode of laser maintenance screen is
0: User mode.
1: Service mode.
On the laser maintenance screen, some data are prohibited to be input because of avoiding
data input accidentally.(Data can only viewed.)
Setting this bit enables data entry.
And setting this bit enables running beam internally with shutter closed in laser tuning screen.
#7 #6 #5 #4 #3 #2 #1 #0
29000 PTC PTB PFB
[Data Type] Bit
PFB Pulse power feedback by actual power presumption is
0: Disabled.
1: Enabled.
PTB Data table screens for actual power presumption are
0: Not displayed.
1: Displayed.
Data cannot be input in case that this parameter is set 0 because the screens are not displayed.
This parameter should be set 0 not to change data accidentally.
PTC Measurement screen of power sensor time constant is
0: Not displayed.
1: Displayed.
Power sensor time constant cannot be measured in case that this parameter is set 0 because
the screens are not displayed.
But, the time constant can be measured by PMC signal.
This parameter should be set 0 not to start measuring the time constant accidentally.
