2.9 Operation of data used at maintenance
Parameters and diagnoses that are often used at maintenance are displayed in a mass.
Parameters can be set from the screen.
Running beam internally with shutter closed can be commanded from the screen
2.9.1How to output the data to memory card with operating the maintenance screen
Pushing soft-key [TUNE] makes displaying laser tuning screen (9 inch CRT image).
Laser tuning screen is composed of 3 pages.
“PAGE↑” and “PAGE↓” keys on MDI panel should be used to change the pages.
Data displayed each page are as follows.
[Laser tuning screen]
[ LASER TUNING ] 1/3
PC:**** FR:**** DU:*** COE:1024
PA:3998 TP:4000 SEQ: 30
RFV RFI DCV DCI DCW
PSU1 4210 1705 2150 390
PSU2 4195 1701 2121 396
PSU3 4155 1688 2100 385
PSU4 4189 1699 2118 391
PSU5 **** **** **** ****
PSU6 **** **** **** ****
PSU7 **** **** **** ****
PSU8 **** **** **** **** ****
>
[ LASER TUNING ] 2/3
15000.2 AGA [*]
15000.3 BMO [*]
15000.4 CLB [*]
15003.2 GVW [*]
15008.5 (DCW) [*]
15201 POWER CALIB. 4 [********]
15204 PWR-CALIB. COE [********]
15207 PWR-COMAND LIMIT [********]
15208 FEEDBACK GAIN [********]
15210 MAXIMUM POWER [********]
>
[ LASER TUNING ] 3/3
15211 MINIMUM POWER [********]
15212 UNCLMP PC CMD-LMT [********]
15215 PWR-INPUT CALIB. [********]
15222 WAIT DISCHARGE [********]
15223 BIAS COMMAND [********]
15242 INT. PRES. OSCIL [********]
15243 INT. PRES. OSCIL [********]
15271 POWER DEC. LIMIT [********]
15306 (POWER TBL ALL 7) [********]
15307 (POWER TBL ALL 8) [********]
>
DISCH CAN
DISCH CAN
DISCH CAN
Previous page
Next page
