The file name should be set by the receiver (HANDY-FILE).
2.10.3 Data Input from and output to memory card with operating ALL-IO screen
(1) The I/O channel should be switched to the memory card by setting 4 in the parameter
(No.0020).
(2) After switching the operation mode to "EDIT", ALL-IO screen should be selected, and
push the soft-key corresponding to the desired data.
Data Soft-key
Power calibration coefficient history data [PW.OFS]
Parts running time data [ACT.TM]
Alarm related to discharging data [DISCH.]
Laser alarm history data [L ALM]
Power feedback table data [PWR FB]
(3) Push soft-key [OPER], and soft-key [PUNCH] and [F READ] are displayed.
Push soft-key [PUNCH] in case of data output. Push soft-key [F READ] in case of data
input.
(4) Set an arbitrary file name set and push soft-key [EXEC].
2.11 Soft-key display
POWER SET DATA 3D.TRN
STATUS
MAINT.
PW.CLB
ACT TM
DISCH. L ALM
PWR FB
PS TC LEAK TUNE
