FANUC Series 16i/160i Additional Manual Page 8

Additional Manual
A-78075E
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/160i –L
Laser maintenance screen function
Specifications
2000.03.06
8/21
Sheet Sheet
M.Sato K.Suzuki
05 2001.08.23 M.Sato Change all page. K.Suzuki
06 2001.10.11 M.Sato Change page 10. K.Suzuki
07 2003.12.04 M.Sato Change all pages. K.Suzuki
08 2003.12.19 M.Sato Change page 4,17. K.Suzuki
09 2004.06.04 M.Sato Change page 14. K.Suzuki
10 2004.06.09 M.Sato Change page 13. K.Suzuki
11 2005.02.23 M.Sato Change all pages.
• Alarm occurring date
• Alarm occurring time
• Alarm number
• Sequence number when the alarm occurs
• Passed time from when sequence number changes to when alarm occurs. (unit is
second)
• Beam output condition (peak power, pulse frequency, pulse duty)
• Actual power
• Power calibration coefficient
• Power supply condition data (RFV,RFI,DCV,DCI,DCW)
• Alarm occurring power supply number ('*' is displayed in the column of the power
supply that the alarm occurs.)
• Contents of alarm of each power supply ('----' is displayed because hardware does
not correspond.)
[ History screen of alarm related to electrical discharge ]
[ ALARM RELATED TO DISCHARGE ] 1/6
PSU DATA AT POWER CALIBRATION END
2001.10.10 10:10:10
PC:4000 FR:2000 DU:100 PA:3998 1234
RFV RFI DCV DCI DCW
PSU1 4210 1705 2150 390 8385
PSU2 4195 1701 2121 396 8399
PSU3 4155 1688 2100 385 8085
PSU4 4189 1699 2118 391 8281
PSU5 4210 1705 2150 390 8385
PSU6 4195 1701 2121 396 8399
PSU7 4155 1688 2100 385 8085
PSU8 4189 1699 2118 391 8281
< Calibration completion date & time
< Power, Frequency, Duty, Power calibration coefficient
< NO.1 Power supply data (RFV,RFI,DCV,DCI,DCW)
< NO.2 〃
< NO.3 〃
< NO.4 〃
< NO.5 〃
< NO.6 〃
< NO.7 〃
< NO.8 〃
[ ALARM RELATED TO DISCHARGE ] 2/6
ALM.4063 LASER GAS/LASER PSU
2001.10.10 10:10:10 SEQ.28 12345678
PC:4000 FR:2000 DU:100 PA:3998 1234
RFV RFI DCV DCI DCW ALM
PSU1 4210 1705 2150 390 8385 ----
PSU2 4195 1701 2121 396 8399 ----
PSU3 4155 1688 2100 385 8085 * ----
PSU4 4189 1699 2118 391 8281 ----
PSU5 4210 1705 2150 390 8385 ----
PSU6 4195 1701 2121 396 8399 ----
PSU7 4155 1688 2100 385 8085 ----
PSU8 4189 1699 2118 391 8281 ----
< Alarm No. & message
< Date, Time, Sequence No., Passed time
< Power, Frequency, Duty, Power calibration coefficient
< NO.1 Power supply data (RFV,RFI,DCV,DCI,DCW,ALM)
< NO.2 〃
< NO.3 〃
< NO.4 〃
< NO.5 〃
< NO.6 〃
< NO.7 〃
< NO.8 〃
