Year 2000 issue of Open CNC (A-76040E Edition 02) Additional Manual Page 10

Additional Manual
EDIT
SHEET
DRAW. NO. CUST
TITLE
DESCRIPTIONDESIG.DATE
Year 2000 issue of OPEN CNC
A
-76040E
9
/
Device Feature Control Display
Phoenix SETUP Utility (Version 1.00)
(C)Phoenix Technologies Ltd. 1985, 1992 All Rights Reserved
Page 2 of 3
** Device Feature Control **
Serial Port: 03F8h Floppy Boot: Enabled
Track Ball: 02F8h
Parallel Port: 03BCh Display: Simultaneous
Video Mode Graphics: Normal
Internal Cache: Enabled Video Mode Text: Normal
Vertical Compensation: Enabled
Esc
Menu
F2
Sys Info Field
Space/-
Value
PgUp/Dn
Page
- Detailed Description of SET-UP Items
Item Description
Serial Port : Set I/O address of serial port 1.
This item has been set as “03F8h”.
Track Ball: Set I/O address of serial port 2.
This item has been set as “02F8h”.
Parallel Port: Set I/O address of parallel port.
This item has been set as “03BCh”.
Internal Cache: Select Enabled/Disabled of internal cache.
Enabled: CPU internal cache is enabled.
Disabled: CPU internal cache is disabled.
Floppy Boot: Select Enabled/Disabled of boot from FDD.
Enabled:
Disabled:
Display: Set the display device. Only “Simultaneous” is permitted.
Video Mode Graphics: Do not care.
Video Mode Text: Do not care.
Vertical Compensation: Set the parameter whether using a full of LCD size.
Only “Enabled” is permitted.
02 99.07.29 Added this page.
